SC2210 Starvis 2MP USB Camera Module
Weinan Electronics this starvis 2MP USB camera module adopts the 1/1.8-inch SC2210 CMOS image sensor with maximum resolution of 1920×1080 at 30fps/ 60fps frame rate. Square sesign, mini size, 72° FOV, high speed USB2.0 interface, default 1.0 meter USB cable, UVC-compliant, plug and play.
Module Main Parameters
- ◐ Product Code: WN-L2111.K310F
- ◐ Module Size: 32*32mm, 38*38mm
- ◐ Image Sensor: 1/1.8-inch SC2210 CMOS Sensor
- ◐ Max. Resolution and Frame Rate: 1920 H x 1080 V, 30FPS/ 60FPS
- ◐ Pixel Size: 4.0*4.0μm
- ◐ Output Format: MJPEG, YUY2, H.264, H.265
- ◐ Field of View: 72°
- ◐ Focus Mode: Fixed Focus/ Manual Focus
- ◐ Shutter Mode: Electronic Rolling Shutter
- ◐ Output & Power Supply: High Speed USB2.0
- ◐ Parameters Controllable, Like Brightness, Contrast, Saturation, Sharpness, etc.
- ◐ UVC-compliant, Plug and Play for Windows, Android, Linux, Mac OS, etc.
Modules Specifications
- ◐ Module Code: WN-L2202.K320L
- ◐ Modue Size: 32*32mm
- ◐ 30fps@1920H x 1080V
- ◐ MJPEG, YUY2, H.264 Formats
- ◐ Module Code: WN-L2202.K320L V2
- ◐ Modue Size: 38*38mm
- ◐ 30fps@1920H x 1080V
- ◐ MJPEG, YUY2, H.264, H.265 Formats
Camera Module Applications
Weinan Electronics camera modules have a wide range of applications like ATM machine, kiosk, automatic vending machine, robot, sanner, virtual reality, medical equipment, machinery equipment, smart TV BOX, advisement player, safety box, notebook, tablet, video door phone, on-the-spot law enforcement, simple security system, teaching system, interactive system, attendance machine, voting system, exam system, driving learning system, biological microscope, micro HD surveillance, endoscope, medical auxiliary equipment, etc.
Customization Service
Can’t find a camera module to fully meet the actual needs of your project? At Weinan Electronics, attentive customization service will definitely help you achieve reliable product vision.
Modification on Off-the-shelf Modules
If our ready made camera modules almost meet your expectations and you need it to be better tailored to your projects, you can contact us for modification.
Complete Customization
Based on our experienced and skilled R&D team, we can provide turnkey solution including mechanical design, hardware, embedded firmware, extra functions.
